SPEC
| neck type | GRX Maple neck |
| body | Quilted Maple Art Grain top/Poplar body |
| fretboard | Rosewood fretboard w/White dot inlay |
| fret | Medium frets |
| bridge | FAT-6 tremolo bridge |
| neck pickup | Infinity R (H) neck pickup (Passive/Ceramic) |
| middle pickup | Infinity RS (S) middle pickup (Passive/Ceramic) |
| bridge pickup | Infinity R (H) bridge pickup (Passive/Ceramic) |
| factory tuning | 1E, 2B, 3G, 4D, 5A, 6E |
| string gauge | .009/.011/.016/.024/.032/.042 |
| hardware color | Chrome |
NECK DIMENSIONS
| Scale : | 648mm/25.5″ |
| a : Width | 42mm at NUT |
| b : Width | 56mm at 22F |
| c : Thickness | 19.5mm at 1F |
| d : Thickness | 21.5mm at 12F |
| Radius : | 400mmR |
SWITCHING SYSTEM
CONTROLS
